F872 Series

Manufacturer: KEMET

Catalog

SAFETY CAPACITORS 1000V 0.068UF 20% LS=15MM

Part	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Termination	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Ratings	Mounting Type	Voltage Rating - DC	Voltage Rating - DC	Voltage Rating - AC	Lead Spacing	Lead Spacing	Tolerance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Applications	Dielectric Material	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]
KEMET F872BP683M480L	0.068 µF	0.571 "	14.5 mm	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	15 mm	0.591 in	20 %	0.335 in	8.5 mm	18 mm	0.709 in	EMI RFI Suppression	Polypropylene (PP) Metallized
KEMET F872FS105M480Z	1 µF			PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	27.5 mm	1.083 in	20 %					EMI RFI Suppression	Polypropylene (PP) Metallized	1.142 in	29 mm
KEMET F872RD125K480Z	1.2 µF			PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	37.5 mm	1.476 in	10 %	0.748 in	19 mm	41 mm	1.614 in	EMI RFI Suppression	Polypropylene (PP) Metallized	1.26 in	32 mm
KEMET F872AL182K480A	1800 pF		7.5 mm	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	10 mm	0.394 in	10 %	0.374 in	9.5 mm	13 mm	0.512 "	EMI RFI Suppression	Polypropylene (PP) Metallized	0.295 in
KEMET F872AL222K480C	2200 pF		7.5 mm	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	10 mm	0.394 in	10 %	0.374 in	9.5 mm	13 mm	0.512 "	EMI RFI Suppression	Polypropylene (PP) Metallized	0.295 in
KEMET F872DO184M480L	0.18 µF	0.728 in	18.5 mm	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	22.5 mm	0.886 in	20 %	0.394 in	10 mm	26 mm	1.024 in	EMI RFI Suppression	Polypropylene (PP) Metallized
KEMET F872BS104M480C	100000 pF			PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	15 mm	0.591 in	20 %	0.394 in	10 mm	18 mm	0.709 in	EMI RFI Suppression	Polypropylene (PP) Metallized	0.63 in	16 mm
KEMET F872BT333M480Z	0.033 çF		0.492 in	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	15 mm	0.591 in	20 %	0.354 in	9 mm	18 mm	0.709 in	EMI RFI Suppression	Polypropylene (PP) Metallized			12.5 mm
KEMET F872DU254M480L	0.25 µF			PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	22.5 mm	0.886 in	20 %	0.512 "	13 mm	26 mm	1.024 in	EMI RFI Suppression	Polypropylene (PP) Metallized				0.866 in	22 mm
KEMET F872AE222J480C	2200 pF	0.315 in	8 mm	PC Pins	-40 C	110 °C	Radial	X1	Through Hole	1 kV	1 kVDC	480 V	10 mm	0.394 in	5 %	0.157 "	4 mm	13 mm	0.512 "	EMI RFI Suppression	Polypropylene (PP) Metallized
