SA18300 Series
Manufacturer: On Shore Technology Inc.
Beta
⌘K
CONN IC DIP SOCKET 18POS GOLD
| Part | Material Flammability Rating | Current Rating (Amps) | Contact Resistance | Mounting Type | Type | Type | Type | Contact Finish - Post | Contact Finish - Mating | Number of Positions or Pins (Grid) | Features | Contact Material - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Post | Pitch - Post | Contact Material - Post [custom] | Contact Finish Thickness - Mating | Housing Material | Pitch - Mating | Pitch - Mating | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 On Shore Technology Inc. | UL94 V-0 | 3 A | 4 mOhm | Through Hole | 7.62 mm | 0.3 in | DIP | Tin | Gold | 18 | Open Frame | Beryllium Copper | 200 µin | 5.08 µm | -40 C | 105 ░C | 0.1 in | 2.54 mm | Brass | Flash | Glass Filled Polyester Thermoplastic | 0.1 " | 2.54 mm | Solder |
