306-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Material - Insulation | Termination Rows | Card Type | Number of Positions | Contact Finish | Gender | Color | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Type | Pitch | Pitch | Mounting Type | Number of Positions/Bay/Row | Contact Material | Read Out | Features | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Tin | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Through Hole | 29 | Copper Alloy | Dual | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Panel Mount Through Hole | 29 | Copper Alloy | Dual | Card Guides | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Panel Mount Through Hole | 29 | Copper Alloy | Dual | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | 3.96 mm | 0.156 in | Panel Mount | 29 | Copper Alloy | Dual | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Tin | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | 3.96 mm | 0.156 in | Panel Mount | 29 | Copper Alloy | Dual | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | 3.96 mm | 0.156 in | Panel Mount | 29 | Copper Alloy | Dual | Card Guides | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Through Hole | 29 | Copper Alloy | Dual | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Tin | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Panel Mount Through Hole | 29 | Copper Alloy | Dual | Card Guides | 4-40 Flush Mount Threaded Insert Top Opening | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder Eyelet(s) | Cantilever | 3.96 mm | 0.156 in | Panel Mount | 29 | Copper Alloy | Dual | Card Guides | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Non Specified - Dual Edge | 58 | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | -40 C | 105 ░C | Solder | Cantilever | 3.96 mm | 0.156 in | Panel Mount Through Hole | 29 | Copper Alloy | Dual | Card Guides | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening |
