845-072 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 72POS 0.100
| Part | Termination Rows | Contact Type | Read Out | Card Thickness [Max] | Card Thickness [Min] | Material - Insulation | Pitch | Pitch | Contact Finish | Contact Material | Gender | Number of Positions/Bay/Row [custom] | Number of Positions | Mounting Type | Color | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows | Termination | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Termination Rows [custom] | Number of Rows [custom] | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Through Hole | Green | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 1 | Solder | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | Through Hole | Green | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Solder Eyelet(s) | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | 36 | |||
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Through Hole | Green | 0.156 " | 3.96 mm | 1 | Wire Wrap | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Right Angle Through Hole | Green | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | 1 | Solder | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | Through Hole | Green | 4-40 Threaded Insert Top Mount Opening | Solder Eyelet(s) | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | 36 | |||||
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Through Hole | Green | 0.128 " | 3.25 mm | 1 | Wire Wrap | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Right Angle Through Hole | Green | 4-40 Threaded Insert Top Mount Opening | 1 | Solder | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | Right Angle Through Hole | Green | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | 36 | |||||
 EDAC Inc. | 1 | Cantilever | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | 72 | Right Angle Through Hole | Green | 0.128 " | 3.25 mm | 1 | Solder | Non Specified - Single Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Cantilever | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 0.1 " | 2.54 mm | Gold | Copper Alloy | Female | 72 | Right Angle Through Hole | Green | 0.156 " | 3.96 mm | Solder | Non Specified - Dual Edge | 125 °C | -40 C | 0.25 Ám | 10 Áin | 2 | 2 | 36 |
