306-039 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 78POS 0.156
| Part | Termination Rows | Material - Insulation | Read Out | Gender | Number of Positions/Bay/Row | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Termination | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Color | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Pitch | Pitch | Contact Finish | Number of Rows [custom] | Contact Type | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Gold | 2 | Cantilever | Non Specified - Dual Edge | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Flush Mount Side Opening Unthreaded | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Solder | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | Card Guides | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Flush Mount Top Opening Unthreaded | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Gold | 2 | Cantilever | Non Specified - Dual Edge | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 0.25 Ám | 10 Áin | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Gold | 2 | Cantilever | Non Specified - Dual Edge | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Flush Mount Top Opening Unthreaded | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | Card Guides | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Dual | Female | 39 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Panel Mount Through Hole | Solder | Floating Bobbin Flush Mount | Green | -40 C | 105 ░C | 78 | 3.96 mm | 0.156 in | Tin | 2 | Cantilever | Non Specified - Dual Edge | 0.116 " | 2.95 mm |
