CF140 Series
Manufacturer: Igus
Beta
⌘K
PVC4C/18AWG TCER 600V FLEX FEET
| Part | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Conductor Material | Length | Number of Conductors | Features | Shield Material | Shield Coverage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Shield Type | Spool Size | Spool Size | Jacket Color | Jacket (Insulation) Material | Conductor Insulation | Cable Type | Conductor Strand | Usage | Ratings | Conductor Strand [custom] | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Igus | 41 strands | 34 AWG | 600 V | Copper Bare | Enter Number of Feet in Order Quantity | 4 | Flame Retardant Oil Resistant UV Resistant | Copper Tinned | 85 % | 0.4 " | 10.16 mm | 18 AWG | Braid | 1000 ft | 304.8 m | Gray | Poly-Vinyl Chloride (PVC) | Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA) | Multi-Conductor | ||||||
Igus | 600 V | Copper Bare | Enter Number of Feet in Order Quantity | 18 | Flame Retardant Oil Resistant UV Resistant | Copper Tinned | 85 % | 0.63 in | 16 mm | 20 AWG | Braid | 1000 ft | 304.8 m | Gray | Poly-Vinyl Chloride (PVC) | Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA) | Multi-Conductor | 26 34 AWG | |||||||
 Igus | 300 V | Copper Bare | Enter Number of Feet in Order Quantity | 25 | Flame Retardant Rip Cord | Copper Tinned | 80 % | 0.886 in | 22.5 mm | 16 AWG | Braid | Gray | Poly-Vinyl Chloride (PVC) | Thermoplastic Elastomer (TPE) | Multi-Conductor | Industrial Control | UL Style 20200 | ||||||||
Igus | 300 V | Copper Bare | Enter Number of Feet in Order Quantity | 4 | Flame Retardant Rip Cord | Copper Tinned | 80 % | 0.354 in | 8.99 mm | 17 AWG | Braid | Gray | Poly-Vinyl Chloride (PVC) | Thermoplastic Elastomer (TPE) | Multi-Conductor | Industrial Control | UL Style 20200 | ||||||||
 Igus | 300 V | Copper Bare | Enter Number of Feet in Order Quantity | 25 | Flame Retardant Rip Cord | Copper Tinned | 80 % | 0.709 " | 18.01 mm | 18 AWG | Braid | 1000 ft | 304.8 m | Gray | Poly-Vinyl Chloride (PVC) | Thermoplastic Elastomer (TPE) | Multi-Conductor | Industrial Control | UL Style 20200 | ||||||
 Igus | 65 | 34 AWG | 600 V | Copper Bare | Enter Number of Feet in Order Quantity | 25 | Flame Retardant Oil Resistant UV Resistant | Copper Tinned | 85 % | 0.85 " | 21.59 mm | 16 AWG | Braid | Gray | Poly-Vinyl Chloride (PVC) | Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA) | Multi-Conductor | ||||||||
Igus | 300 V | Copper Bare | Enter Number of Feet in Order Quantity | 5 | Flame Retardant Rip Cord | Copper Tinned | 80 % | 0.374 in | 9.5 mm | 17 AWG | Braid | Gray | Poly-Vinyl Chloride (PVC) | Thermoplastic Elastomer (TPE) | Multi-Conductor | Industrial Control | UL Style 20200 | ||||||||
 Igus | 34 AWG | 600 V | Copper Bare | Enter Number of Feet in Order Quantity | 4 | Flame Retardant Oil Resistant UV Resistant | Copper Tinned | 85 % | 0.64 " | 16.26 mm | 10 AWG | Braid | Gray | Poly-Vinyl Chloride (PVC) | Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA) | Multi-Conductor | 259 | ||||||||
Igus | 41 strands | 34 AWG | 600 V | Copper Bare | Enter Number of Feet in Order Quantity | 25 | Flame Retardant Oil Resistant UV Resistant | Copper Tinned | 85 % | 18 AWG | Braid | 1000 ft | 304.8 m | Gray | Poly-Vinyl Chloride (PVC) | Nylon Poly-Vinyl Chloride (PVC) Polyamide (PA) | Multi-Conductor | 19.81 mm | 0.78 " | ||||||
Igus | 300 V | Copper Bare | Enter Number of Feet in Order Quantity | 3 | Flame Retardant Rip Cord | Copper Tinned | 80 % | 0.35 in | 8.89 mm | 16 AWG | Braid | 1000 ft | 304.8 m | Gray | Poly-Vinyl Chloride (PVC) | Thermoplastic Elastomer (TPE) | Multi-Conductor | Industrial Control | UL Style 20200 |
