SDS100 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN D-SUB PLUG 50POS SLDR CUP
| Part | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Wire Gauge | Voltage Rating | Contact Material | Contact Form | Connector Style | Contact Finish Thickness | Flange Feature | Number of Positions | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish | Material Flammability Rating | Number of Rows [custom] | Current Rating (Amps) | Connector Type | Mounting Type | Contact Type | Features | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Shell Size, Connector Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 50 | 5 | D DD | Gold | UL94 V-0 | 3 | 3 A | Plug Male Pins | Free Hanging (In-Line) | Signal | Grounding Indents | |||
 Sullins Connector Solutions | White | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | D-Sub | Flash | Housing/Shell (Unthreaded) | 9 | 1 | DE E | Gold | UL94 V-0 | 2 | 3 A | Receptacle Female Sockets | Free Hanging (In-Line) | Signal | |||||
 Sullins Connector Solutions | White | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | 4-40 | 9 | 1 | DE E | Gold | UL94 V-0 | 2 | 3 A | Receptacle Female Sockets | Free Hanging (In-Line) | Signal | ||||
 Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 9 | 1 | DE E | Gold | UL94 V-0 | 2 | 3 A | Plug Male Pins | Free Hanging (In-Line) | Signal | Grounding Indents | |||
 Sullins Connector Solutions | White | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 9 | 1 | DE E | Gold | UL94 V-0 | 2 | 3 A | Receptacle Female Sockets | Free Hanging (In-Line) | Signal | ||||
 Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 25 | Gold | UL94 V-0 | 2 | 3 A | Receptacle Female Sockets | Free Hanging (In-Line) | Signal | B DB | 3 | ||||
Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 37 | Gold | UL94 V-0 | 2 | 3 A | Plug Male Pins | Free Hanging (In-Line) | Signal | Grounding Indents | DC C | 4 | |||
 Sullins Connector Solutions | White | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 25 | Gold | UL94 V-0 | 2 | 3 A | Plug Male Pins | Free Hanging (In-Line) | Signal | Grounding Indents | B DB | 3 | |||
 Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | 4-40 Mating Side Female Screwlock | 9 | 1 | DE E | Gold | UL94 V-0 | 2 | 3 A | Receptacle Female Sockets | Free Hanging (In-Line) | Signal | ||||
 Sullins Connector Solutions | Black | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 105 ░C | 22 AWG | 250 V | Brass | Stamped | D-Sub | Flash | Housing/Shell (Unthreaded) | 15 | Gold | UL94 V-0 | 2 | 3 A | Plug Male Pins | Free Hanging (In-Line) | Signal | Grounding Indents | 2 |
