Axicom HF3 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SIGNAL RELAY 5VDC 2A SPDT(16X9.4X10.5)MM SMD
| Part | Contact Material | Coil Resistance | Release Time | Operate Time | Must Release Voltage | Must Operate Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Rating (Current) | Coil Current | Mounting Type | Coil Type | Contact Form | Switching Voltage [Max] | Termination Style | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Gold (Au) Silver (Ag) | 178 Ohms | 5 ms | 5 ms | 0.5 VDC | 3.75 VDC | -55 C | 85 °C | 2 A | 28 mA | Surface Mount | Non Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 5 VDC |
 TE Connectivity AMP Connectors | 4 ms | 5 ms | 0.5 VDC | 3.75 VDC | -55 C | 85 °C | 2 A | 28 mA | Surface Mount | Non Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 5 VDC | ||
 TE Connectivity AMP Connectors | 5 ms | 5 ms | 3.38 VDC | -55 C | 85 °C | 2 A | 31 mA | Surface Mount | Dual Coil Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 4.5 VDC | |||
 TE Connectivity AMP Connectors | 5 ms | 5 ms | 1.2 VDC | 9 VDC | -55 C | 85 °C | 2 A | 11.7 mA | Surface Mount | Non Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 12 VDC | ||
 TE Connectivity AMP Connectors | Gold (Au) Silver (Ag) | 257 Ohms | 5 ms | 5 ms | 0.6 VDC | 4.5 VDC | -55 C | 85 °C | 2 A | 23.3 mA | Surface Mount | Non Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | |
 TE Connectivity AMP Connectors | 5 ms | 5 ms | 18 VDC | -55 C | 85 °C | 2 A | 5.8 mA | Surface Mount | Dual Coil Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 24 VDC | |||
 TE Connectivity AMP Connectors | Gold (Au) Silver (Ag) | 64 Ohms | 2 ms | 3 ms | 2.25 VDC | -55 C | 85 °C | 2 A | 47 mA | Surface Mount | Dual Coil Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | ||
 TE Connectivity AMP Connectors | 5 ms | 5 ms | 6.75 VDC | -55 C | 85 °C | 2 A | 15.7 mA | Surface Mount | Dual Coil Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 9 VDC | |||
 TE Connectivity AMP Connectors | Gold (Au) Silver (Ag) | 1030 Ohms | 5 ms | 5 ms | 9 VDC | -55 C | 85 °C | 2 A | 11.7 mA | Surface Mount | Dual Coil Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 12 VDC | |
 TE Connectivity AMP Connectors | 5 ms | 5 ms | 0.45 VDC | 3.38 VDC | -55 C | 85 °C | 2 A | 31 mA | Surface Mount | Non Latching | SPDT (1 Form C) | 220 VDC 250 VAC | Gull Wing | 4.5 VDC |
