EHRJ45 Series
Manufacturer: Switchcraft Inc.
Beta
⌘K
CONN MOD JACK 8P8C R/A SHLD
| Part | Housing Material | Contact Material | Tab Direction | LED Color | Orientation | Connector Type | Shielding | Number of Ports | Ratings | Termination | Number of Rows | Contact Finish | Number of Positions/Contacts | Convert From (Adapter End) | Mounting Type | Type | Shield Material | Shell Material, Finish | Convert To (Adapter End) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Switchcraft Inc. | Thermoplastic | Copper Alloy | User Selectable | Does Not Contain LED | 90 ° | Jack | Shielded | 1 | Cat5e | Color Coded Block IDC | 1 | Gold | 8p8c (RJ45 Ethernet) | ||||||
 Switchcraft Inc. | Thermoplastic | Copper Alloy | User Selectable | Does Not Contain LED | 90 ° | Jack | Unshielded | 1 | Cat6 | Color Coded Block IDC | 1 | Gold | 8p8c (RJ45 Ethernet) | ||||||
 Switchcraft Inc. | Thermoplastic | Unshielded | Cat5e | Jack 8p8c (RJ45) | Flange Panel Mount | Coupler | Copper Alloy | Thermoplastic | 8p8c (RJ45) Jack | ||||||||||
Switchcraft Inc. | Thermoplastic | Copper Alloy | User Selectable | Does Not Contain LED | 90 ° | Jack | Shielded | 1 | Cat6 | Color Coded Block IDC | 1 | Gold | 8p8c (RJ45 Ethernet) | ||||||
 Switchcraft Inc. | Thermoplastic | Shielded | Cat6 | Jack 8p8c (RJ45) | Flange Panel Mount | Coupler | Copper Alloy | Thermoplastic | 8p8c (RJ45) Jack | ||||||||||
 Switchcraft Inc. | Thermoplastic | Shielded | Cat5e | Jack 8p8c (RJ45) | Panel Mount Square Flange | Coupler | Copper Alloy | Thermoplastic | 8p8c (RJ45) Jack | ||||||||||
 Switchcraft Inc. | Thermoplastic | Unshielded | Cat6 | Jack 8p8c (RJ45) | Panel Mount Square Flange | Coupler | Copper Alloy | Thermoplastic | 8p8c (RJ45) Jack | ||||||||||
 Switchcraft Inc. | Thermoplastic | Shielded | Cat6a | Jack 8p8c (RJ45) | Panel Mount Square Flange | Coupler | Copper Alloy | 8p8c (RJ45) Jack |
