89 Series

Manufacturer: Ohmite

Catalog

WIREWOUND RESISTORS - CHASSIS MOUNT 10WATT 50OHM 1%

Part	Temperature Coefficient	Tolerance	Mounting Feature	Coating, Housing Type	Package / Case	Composition	Operating Temperature [Min]	Operating Temperature [Max]	Resistance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lead Style	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Power (Watts)	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)
Ohmite 810F50RE	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	50 Ohms	0.4 in	10.16 mm	Solder Lugs	19.05 mm	0.812 "	0.75 "	20.63 mm	10 W
Ohmite 850FR15E	90 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	0.15 Ohms	0.62 in	15.75 mm	Solder Lugs		29.36 mm	49.23 mm		50 W	1.156 in	1.938 in
Ohmite 805F3K5E	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound			3.5 kOhms			Solder Lugs		16.5 mm	15.9 mm		5 W	0.65 "	0.626 in	0.346 "	8.8 mm
Ohmite 825F2K5E	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	2500 Ohms			Solder Lugs		27.79 mm	26.98 mm		25 W	1.094 "	1.062 "	0.556 in	14.12 mm
Ohmite 810F2R0E	50 ppm/░C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	2 Ohms	0.4 in 0.433 in	10.16 mm 11 mm	Solder Lugs	19.05 mm	0.812 " 21 mm	0.75 " 19.9 mm	20.63 mm	10 W	0.827 in	0.783 in
Ohmite 825F2R0E	50 ppm/░C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	2 Ohms			Solder Lugs		27.79 mm	26.98 mm		25 W	1.094 "	1.062 "	0.556 in	14.12 mm
Ohmite 825F10RE	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound			10 Ohms			Solder Lugs		28 mm	27.3 mm		25 W	1.102 "	1.075 "	0.583 in	14.8 mm
Ohmite 805F100E	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	100 Ohms			Solder Lugs		16.41 mm	15.24 mm		5 W	0.646 in	0.6 "	0.33 in		8.38 mm
Ohmite 825F25RE	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	25 Ohms			Solder Lugs		27.79 mm	26.98 mm		25 W	1.094 "	1.062 "	0.556 in	14.12 mm
Ohmite 810F3K5E	20 ppm/°C	1 %	Flanges	Aluminum	Axial Box	Wirewound	-55 C	275 °C	3.5 kOhms	0.4 in	10.16 mm	Solder Lugs	19.05 mm	0.812 "	0.75 "	20.63 mm	10 W
