0.374 DOUBLE ROW Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
BARRIER TERMINAL BLOCKS 4P.374 DR BARRIER SS QC ASSY
| Part | Current Rating (Amps) | Number of Wire Entries | Terminal Block Type | Top Termination | Number of Rows [custom] | Barrier Type | Color | Pitch | Pitch | Features | Voltage Rating | Number of Circuits | Wire Gauge [Max] | Wire Gauge [Min] | Bottom Termination | Number of Wire Entries [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 20 A | 4 | Barrier Block | Screws with Quick Connect Tabs | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 4 | 22 AWG | 12 AWG | Closed | |
 TE Connectivity AMP Connectors | 20 A | Barrier Block | Screws | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 18 | 22 AWG | 12 AWG | Closed | 36 | |
 TE Connectivity AMP Connectors | 20 A | 4 | Barrier Block | Screws | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 2 | 22 AWG | 12 AWG | Closed | |
TE Connectivity AMP Connectors | 20 A | 54 | Barrier Block | Screws | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 27 | 22 AWG | 12 AWG | Closed | |
 TE Connectivity AMP Connectors | 20 A | Barrier Block | Screws with Quick Connect Tabs | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 7 | 22 AWG | 12 AWG | Closed | 7 | |
 TE Connectivity AMP Connectors | 20 A | 12 | Barrier Block | Screws with Captive Plate | 2 | 2 Wall (Dual) | Black | 0.375 in | 9.53 mm | Flange | 300 VDC | 6 | 22 AWG | 12 AWG | Closed | |
 TE Connectivity AMP Connectors | 20 A | 28 | Barrier Block | Screws | 2 | 2 Wall (Dual) | Black | 0.374 in | 9.5 mm | Flange | 300 VDC | 14 | 22 AWG | 12 AWG | Closed |
