842-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 36POS 0.100
| Part | Read Out | Gender | Termination Rows | Number of Rows | Contact Type | Termination | Number of Positions/Bay/Row | Contact Material | Pitch | Pitch | Number of Positions | Flange Feature | Card Type | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Contact Finish | Material - Insulation | Color | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Positions/Bay/Row [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Solder Eyelet(s) | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | |||||
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Wire Wrap | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Floating Bobbin Flush Mount | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Dual | Female | Cantilever | Solder | Copper Alloy | 0.1 " | 2.54 mm | 36 | Floating Bobbin Flush Mount | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.116 " | 2.95 mm | 2 | 18 | 2 | |||
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Solder | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Flush Mount Side Opening Unthreaded | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Wire Wrap | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Flush Mount Top Opening Unthreaded | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Solder | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Gold | Diallyl Phthalate (DAP) | Green | |||||
 EDAC Inc. | Single | Female | 1 | 1 | Cantilever | Solder | 36 | Copper Alloy | 0.1 " | 2.54 mm | 36 | Flush Mount Top Opening Unthreaded | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Dual | Female | Cantilever | Wire Wrap | Copper Alloy | 0.1 " | 2.54 mm | 36 | Floating Bobbin Flush Mount | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.116 " | 2.95 mm | 2 | 18 | 2 | |||
 EDAC Inc. | Dual | Female | Cantilever | Solder | Copper Alloy | 0.1 " | 2.54 mm | 36 | Floating Bobbin Flush Mount | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 0.116 " | 2.95 mm | 2 | 18 | 2 | |||
 EDAC Inc. | Dual | Female | Cantilever | Solder | Copper Alloy | 0.1 " | 2.54 mm | 36 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Gold | Diallyl Phthalate (DAP) | Green | 2 | 18 | 2 |
