SRP1038WA Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTORS - SMD IND,11X10X3.8MM,5.6UH+/-20%,10.5A,SHD AEC-Q200
| Part | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Inductance Frequency - Test | Mounting Type | Ratings | Current Rating (Amps) | Inductance | Material - Core | Shielding | Frequency - Self Resonant | Operating Temperature [Min] | Operating Temperature [Max] | Height - Seated (Max) | Height - Seated (Max) [Max] | Package / Case | Tolerance | DC Resistance (DCR) [Max] | Q @ Freq | Current - Saturation (Isat) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 0.433 in | 0.394 in | 10 mm | 11 mm | 100 kHz | Surface Mount | AEC-Q200 | 10.5 A | 5.6 µH | Metal | Shielded | 13 MHz | -55 C | 165 °C | 4 mm | 0.157 in | Nonstandard | 20 % | 17 mOhm | 20 100 kHz | |
 Bourns Inc. | 0.433 in | 0.394 in | 10 mm | 11 mm | 100 kHz | Surface Mount | AEC-Q200 | 8.5 A | 8.2 µH | Metal | Shielded | 12 MHz | -55 C | 165 °C | 4 mm | 0.157 in | Nonstandard | 20 % | 25.3 mOhm | 20 100 kHz | 9 A |
