Modular Connectors / Ethernet Connectors SMT 1X1 TAB DOWN
Modular Connectors / Ethernet Connectors SMT 1X1 TAB DOWN
| Part | Contact Material | Contact Finish | Height Above Board | Height Above Board | Number of Ports | Shielding | Number of Rows | LED Color | Tab Direction | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Connector Type | Mounting Type | Features | Termination | Housing Material | Contact Finish Thickness | Contact Finish Thickness | Shield Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | Phosphor Bronze | Gold | 0.545 in | 13.84 mm | 1 | Shielded | 1 | Does Not Contain LED | Down | 10/100 Base-TX AutoMDIX | 70 °C | 0 °C | 90 ° | RJ45 | Surface Mount | Board Guide | Solder | ||||
 Pulse Electronics | Phosphor Bronze | Gold | 0.545 in | 13.84 mm | 1 | Shielded | 1 | Does Not Contain LED | Down | 10/100 Base-TX AutoMDIX | 70 °C | 0 °C | 90 ° | RJ45 | Surface Mount | Board Guide | Solder | Thermoplastic | 0.38 µm | 15 µin | Brass |
