895-045 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 45POS 0.100
| Part | Material - Insulation | Termination Rows | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Color | Pitch | Pitch | Number of Rows | Gender | Contact Type | Number of Positions | Contact Material | Card Type | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Flange Feature | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | M3 Threaded Insert Top Mount Opening | Through Hole | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | 45 | Through Hole | 3.25 mm | 0.128 " | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | 45 | Floating Bobbin Top Mount Opening | Through Hole | 2.95 mm | 0.116 " |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | Through Hole | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | Floating Bobbin Top Mount Opening | Through Hole | 2.95 mm | 0.116 " |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | 45 | Right Angle Through Hole | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | Side Mount Opening Unthreaded | Through Hole | 3.25 mm | 0.128 " |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | Flush Mount Top Opening Unthreaded | Through Hole | 3.96 mm | 0.156 " |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 0.25 Ám | 10 Áin | 45 | Floating Bobbin Flush Mount | Through Hole | 2.95 mm | 0.116 " |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | 125 °C | -40 C | Gold | Black | 0.1 " | 2.54 mm | 1 | Female | Cantilever | 45 | Copper Alloy | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 0.25 Ám | 10 Áin | 45 | 4-40 Threaded Insert Top Mount Opening | Through Hole |
