083619 Series
Manufacturer: Molex
Beta
⌘K
CONN MICRO-D PLUG 15POS R/A SLDR
| Part | Shell Material, Finish | Connector Type | Dielectric Material | Contact Finish | Number of Rows | Mounting Type | Contact Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Backset Spacing | Backset Spacing | Number of Positions | Material Flammability Rating | Contact Material | Termination | Contact Finish Thickness | Contact Finish Thickness | Features | Connector Style | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Nickel Plated Steel | Male Pins Plug | Liquid Crystal Polymer (LCP) | Gold | 2 | Panel Mount Right Angle Through Hole | Signal | 0.05 | 0.05 | 125 °C | -40 °C | 6.81 mm | 0.268 in | 15 | UL94 V-0 | Copper Alloy | Solder | 15 µin | 0.38 µm | Board Lock Shielded | D-Type Micro-D - Stacked | Female Screwlock (2-56) Mating Side |
Molex | Nickel Plated Steel | Male Pins Plug | Liquid Crystal Polymer (LCP) | Gold | 2 | Panel Mount Right Angle Through Hole | Signal | 0.05 | 0.05 | 125 °C | -55 °C | 6.86 mm | 0.27 in | 15 | UL94 V-0 | Copper Alloy | Solder | 15 µin | 0.38 µm | Board Lock Shielded | D-Type Micro-D - Stacked | Housing/Shell (Unthreaded) |
 Molex | Nickel Plated Steel | Male Pins Plug | Liquid Crystal Polymer (LCP) | Gold | 2 | Panel Mount Right Angle Through Hole | Signal | 0.05 | 0.05 | 125 °C | -55 °C | 6.86 mm | 0.27 in | 9 | UL94 V-0 | Copper Alloy | Solder | 15 µin | 0.38 µm | Board Lock Shielded | D-Type Micro-D - Stacked | Female Screwlock (2-56) Mating Side |
