9455MN Series

Catalog

CABLE 9COND 20AWG BLUE

Part	Conductor Material	Conductor Insulation	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	Jacket (Insulation) Material	Ratings	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Wire Gauge	Number of Conductors	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Usage	Operating Temperature [Max]	Operating Temperature [Min]	Length [x]	Length [x]
Belden Inc. 9455MN 0061000	Copper Tinned	Polypropylene (PP)	300 VDC	0.238 "	6.05 mm	Blue	Poly-Vinyl Chloride (PVC)	UL Style 2937	304.8 m	1000 ft	26	34 AWG	20 AWG	9	0.406 mm	0.016 in	Multi-Conductor	Audio Control Instrumentation	80 °C	-20 ░C
Belden Inc. 9455MN 0041000	Copper Tinned	Polypropylene (PP)	300 VDC	0.238 "	6.05 mm	Yellow	Poly-Vinyl Chloride (PVC)	UL Style 2937	304.8 m	1000 ft	26	34 AWG	20 AWG	9	0.406 mm	0.016 in	Multi-Conductor	Audio Control Instrumentation	80 °C	-20 ░C
Belden Inc. 9455MN 0081000	Copper Tinned	Polypropylene (PP)	300 VDC	0.238 "	6.05 mm	Gray	Poly-Vinyl Chloride (PVC)	UL Style 2937	304.8 m	1000 ft	26	34 AWG	20 AWG	9	0.406 mm	0.016 in	Multi-Conductor	Audio Control Instrumentation	80 °C	-20 ░C
Belden Inc. 9455MN 006100	Copper Tinned	Polypropylene (PP)	300 VDC	0.238 "	6.05 mm	Blue	Poly-Vinyl Chloride (PVC)	UL Style 2937			26	34 AWG	20 AWG	9	0.406 mm	0.016 in	Multi-Conductor	Audio Control Instrumentation	80 °C	-20 ░C	100 ft	30.5 m
