AC/DC Power Modules 3.5W 85-305Vin 24Vout 146mA
AC/DC Power Modules 3.5W 85-305Vin 24Vout 146mA
| Part | Package / Case | Efficiency | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Mounting Type | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Current - Output (Max) [Max] | Type | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Number of Outputs | Applications | Voltage - Output 1 | Line Regulation | Load Regulation | Weight [custom] | Weight [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Recom Power | 9-DIP Module 4 Leads | 77 % | -40 °C | 85 °C | CE cURus | Through Hole | 3.5 W | 305 VAC 430 VDC | 85 VAC 120 VDC | 1.06 A | Enclosed | 0.86 in | 21.8 mm | 31.7 mm | 1.05 in | 1.25 in | 26.7 mm | 1 | Household Appliances ITE (Commercial) | 3.3 V | ||||
 Recom Power | 9-DIP Module 4 Leads | 80 % | -40 °C | 85 °C | CE cURus | Through Hole | 3.5 W | 305 VAC 430 VDC | 85 VAC 120 VDC | 700 mA | Enclosed | 0.86 in | 21.8 mm | 31.7 mm | 1.05 in | 1.25 in | 26.7 mm | 1 | Household Appliances ITE (Commercial) | 5 V | ||||
 Recom Power | 9-DIP Module 4 Leads | 83 % | -40 °C | 85 °C | CE cURus | Through Hole | 3.5 W | 305 VAC 430 VDC | 85 VAC 120 VDC | 291 mA | Enclosed | 0.86 in | 21.8 mm | 31.7 mm | 1.05 in | 1.25 in | 26.7 mm | 1 | Household Appliances ITE (Commercial) | 12 V | 0.5 % | 1 % | 0.069 lb | 31.3 g |
 Recom Power | 9-DIP Module 4 Leads | 83 % | -40 °C | 85 °C | CE cURus | Through Hole | 3.5 W | 305 VAC 430 VDC | 85 VAC 120 VDC | 233 mA | Enclosed | 0.86 in | 21.8 mm | 31.7 mm | 1.05 in | 1.25 in | 26.7 mm | 1 | Household Appliances ITE (Commercial) | 15 V |
