2010 Series

Catalog

CBL RIBN 34COND 0.05 WHITE 50'

Part	First Conductor Mark	Length	Length	Insulation Resistance	Length [x]	Length [x]	Conductor Material	Ribbon Width [custom]	Ribbon Width [custom]	Number of Conductors	Jacket Color	Ratings	Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Shielding	Jacket (Insulation) Material	Wire Gauge	Pitch	Pitch	Features	Cable Type	Ribbon Thickness	Ribbon Thickness
3M Electronic Specialty 2010/34 100SF	Blue	3.05 m 7.62 m 30.48 m	10 ft 25 ft 100 '	10 GOhm	50 ft	15.24 m	Copper Tinned	43.18 mm	1.7 in	34	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/09 100SF	Blue	7.62 m 30.48 m	25 ft 100 '	10 GOhm	50 ft	15.24 m	Copper Tinned	11.43 mm	0.45 in	9	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/30 100SF	Blue	7.62 m 30.48 m	25 ft 100 '	10 GOhm			Copper Tinned	38.1 mm	1.5 in	30	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/16 100SF	Blue	3.05 m 7.62 m 30.48 m	10 ft 25 ft 100 '	10 GOhm	50 ft	15.24 m	Copper Tinned	20.32 mm	0.8 in	16	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/37 100SF	Blue	3.05 m 7.62 m 30.48 m	10 ft 25 ft 100 '	10 GOhm	50 ft	15.24 m	Copper Tinned	46.99 mm	1.85 in	37	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/20 100	Blue	30.48 m	100 '	10 GOhm			Copper Tinned	25.4 mm	1 in	20	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/26 100	Blue	30.48 m	100 '	10 GOhm			Copper Tinned	33.02 mm	1.3 in	26	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/40 100SF	Blue	7.62 m 30.48 m	25 ft 100 '	10 GOhm			Copper Tinned	50.8 mm	2 in	40	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/60 100SF	Blue	3.05 m 7.62 m 30.48 m	10 ft 25 ft 100 '	10 GOhm			Copper Tinned	76.2 mm	3 in	60	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
3M Electronic Specialty 2010/15 100SF	Blue	7.62 m 30.48 m	25 ft 100 '	10 GOhm	50 ft	15.24 m	Copper Tinned	19.05 mm	0.75 in	15	White	UL Style 20930	30 V	-20 ░C	105 ░C	36 AWG	7 Strands	Unshielded	Polyolefin (PO)	28 AWG	0.05 in	1.27 mm	Splice Free Zippable	Flat Cable	0.89 mm	0.035 in
