har-flex-r-hybrid Series
Manufacturer: HARTING
CONNECTOR: PCB TO PCB; SOCKET; MALE; PIN: 20(4+16); STRAIGHT; SMT
| Part | Current Rating (Amps) | Insulation Height [z] | Insulation Height [z] | Contact Type | Insulation Color | Contact Length - Mating | Contact Length - Mating | Connector Type | Fastening Type | Shrouding | Voltage Rating | Voltage Rating | Style | Insulation Material | Contact Finish - Mating | Mounting Type | Number of Positions Loaded | Contact Finish - Post | Features | Number of Positions [custom] | Number of Positions [custom] | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Termination | Contact Shape | Material Flammability Rating | Number of Rows [custom] | Contact Length - Post | Contact Length - Post | Number of Positions [Max] | Row Spacing - Mating | Row Spacing - Mating | Insulation Height | Insulation Height | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
HARTING | 20 A | 0.319 in | 8.1 mm | Male Blade Male Pin | Black | 4.6 mm | 0.181 in | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Surface Mount | All | Tin | Board Guide Pick and Place Solder Retention | 16 | 4 | 20 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | ||||||||
HARTING | 21.5 A | Female Socket | Black | Receptacle | Push-Pull | 50 VAC | 120 VDC | Gold | Surface Mount Right Angle Through Hole | All | Tin | Board Guide Solder Retention | 26 | 6 | -55 C | 125 °C | Solder | UL94 V-0 | 2 | 2.2 mm | 0.087 in | 32 | 0.05 in | 1.27 mm | 3.05 mm | 0.12 in | |||||||||||
HARTING | 21.5 A | Male Pin | Black | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC 125 VDC | Board to Cable/Wire | Liquid Crystal Polymer (LCP) | Gold | Right Angle Surface Mount | All | Tin | Board Guide Solder Retention | 26 | 6 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular | UL94 V-0 | 2 | 32 | 0.05 in | 1.27 mm | |||||||||||
HARTING | 20 A | Female Socket | Black | Receptacle | Push-Pull | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Surface Mount | All | Tin | Board Guide Pick and Place Solder Retention | 16 | 4 | 20 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | 9.05 mm | 0.356 " | General Purpose | ||||||||||
HARTING | 21.5 A | Male Pin | Black | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC 125 VDC | Board to Cable/Wire | Liquid Crystal Polymer (LCP) | Gold | Right Angle Surface Mount | All | Tin | Board Guide Solder Retention | 16 | 4 | 20 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular | UL94 V-0 | 2 | 0.05 in | 1.27 mm | |||||||||||
HARTING | 20 A | 0.319 in | 8.1 mm | Male Blade Male Pin | Black | 4.6 mm | 0.181 in | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Surface Mount | All | Tin | Board Guide Pick and Place Solder Retention | 44 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | ||||||||||
HARTING | 22.5 A | 0.167 in | 4.24 mm | Male Blade Male Pin | Black | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Right Angle Surface Mount | All | Tin | Board Guide Solder Retention | 44 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | 4.25 mm | 0.167 " | ||||||||||
HARTING | 21.5 A | Female Socket | Black | Receptacle | Push-Pull | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Surface Mount Through Hole | All | Tin | Board Guide Pick and Place Solder Retention | 44 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | 2.5 mm | 0.098 in | 9.05 mm | 0.356 " | General Purpose | ||||||||||
HARTING | 21.5 A | 0.319 in | 8.1 mm | Male Blade Male Pin | Black | 4.6 mm | 0.181 in | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC | 120 VDC | Board to Board Cable | Liquid Crystal Polymer (LCP) | Gold | Surface Mount Through Hole | All | Tin | Board Guide Pick and Place Solder Retention | 44 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular Square | UL94 V-0 | 2 | ||||||||||
HARTING | 21.5 A | 0.319 in | 8.1 mm | Male Pin | Black | Header | Push-Pull | Shrouded - 4 Wall | 50 VAC 125 VDC | Board to Cable/Wire | Liquid Crystal Polymer (LCP) | Gold | Through Hole | All | Tin | Board Guide Solder Retention | 26 | 6 | -55 C | 125 °C | Copper Alloy | Solder | Rectangular | UL94 V-0 | 2 | 2.5 mm | 0.098 in | 32 | 0.05 in | 1.27 mm |
