4614 Series

Catalog

IDC CONNECTOR, IDC PLUG, MALE, 2.54 MM, 2 ROW, 14 CONTACTS, CABLE MOUNT

Part	Features	Cable Termination	Color	Row Spacing	Row Spacing	Contact Type	Wire Type	Contact Finish Thickness	Contact Finish Thickness	Wire Gauge [Max]	Wire Gauge	Wire Gauge [Min]	Connector Type	Pitch	Pitch	Number of Positions	Mounting Type	Contact Finish	Number of Rows [custom]	Fastening Type
3M Electronic Specialty 4614-6000	Feed Through	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2
3M Electronic Specialty 4614-7000	Closed End	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2
3M Electronic Specialty 4614-6301	Feed Through	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks Long
3M Electronic Specialty 4614-7001	Closed End	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2
3M Electronic Specialty 4614-7005	Closed End	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2
3M Electronic Specialty 4614-7301	Closed End	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks Long
3M Electronic Specialty 4614-7305	Closed End Mounting Flange	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks Long
3M Electronic Specialty 4614-6300	Feed Through	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks Long
3M Electronic Specialty 4614-7205	Closed End	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks
3M Electronic Specialty 4614-6205	Feed Through	IDC	Gray	2.54 mm	0.1 "	Male Pin	Discrete Ribbon Cable	30 Áin	0.76 Ám	28 AWG	Stranded or Solid	26 AWG	Plug	0.1 "	2.54 mm	14	Free Hanging (In-Line)	Gold	2	Latch Lock/Eject Hooks
