TMC6140 Series
Manufacturer: Analog Devices Inc./Maxim Integrated
Beta
⌘K
LOW VOLTAGE BLDC MOTOR DRIVER 5 TO 30V, FOR EXTERNAL N-CHANNEL MOSFETS, INTEGRATED LOWSIDE CHARGEPUMP FOR LOW RDSON AT LOW BATTERY VOLTAGE
| Part | Applications | Motor Type - AC, DC | Voltage - Load [Min] | Voltage - Load [Max] | Supplier Device Package [y] | Supplier Device Package [x] | Supplier Device Package | Function | Output Configuration | Technology | Current - Output | Operating Temperature [Min] | Operating Temperature [Max] | Motor Type - Stepper | Voltage - Supply [Max] | Voltage - Supply [Min] | Package / Case | Mounting Type | Interface |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Analog Devices Inc./Maxim Integrated | Fan Controller | Brushless DC (BLDC) | 5 V | 30 V | 6 | 5 | 36-QFN | Driver - Fully Integrated Control and Power Stage | Pre-Driver - Half Bridge (3) | NMOS | 100 A | -40 C | 125 °C | Multiphase | 30 VDC | 5 V | 36-VFQFN Exposed Pad | Surface Mount | Parallel |
 Analog Devices Inc./Maxim Integrated | General Purpose | Brushless DC (BLDC) PMSM | 5 V | 30 V | 6 | 5 | 36-QFN | Driver - Fully Integrated Control and Power Stage | Pre-Driver - Half Bridge (3) | Power MOSFET | 500 mA | -40 C | 125 °C | Multiphase | 3.6 V | 3 V | 36-VFQFN Exposed Pad | Surface Mount |
