AD561 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

DIGITAL TO ANALOG CONVERTERS - DAC IC, MONO 10-BIT D/A CONV

Part	Output Type	Architecture	Differential Output	Voltage - Supply, Digital (Max)	Voltage - Supply, Digital (Min)	Number of D/A Converters	Data Interface	Settling Time (Typical)	Reference Type	Package Length	Package Name	Package Width	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Number of Bits	INL (LSB) Tolerance	DNL (LSB) Tolerance	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 1 Min)	Voltage - Supply, Analog (Range 2 Min)	Settling Time	Package / Case
Analog Devices Inc./Maxim Integrated AD561JNZ	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel	250 ns	Internal	0.3 in	16-DIP 16-PDIP	7.62 mm	70 °C	0 °C	Through Hole	10 bits	0.25 LSB	0.5 LSB	16.5 V	16.5 V	4.5 V	-10.8 V
Analog Devices Inc./Maxim Integrated AD561JD	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel	250 ns	Internal	0.3 in	16-CDIP	7.62 mm	70 °C	0 °C	Through Hole	10 bits	0.25 LSB	0.5 LSB	16.5 V	16.5 V	4.5 V	-10.8 V
Analog Devices Inc./Maxim Integrated JM38510/13301BEA
Analog Devices Inc./Maxim Integrated AD561KNZ	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel		Internal	0.3 in	16-DIP 16-PDIP	7.62 mm	70 °C	0 °C	Through Hole	10 bits	0.125 LSB	0.25 LSB	16.5 V	16.5 V	4.5 V	-10.8 V	250 µs
Analog Devices Inc./Maxim Integrated AD561JCHIPS	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel		Internal		Die		70 °C	0 °C	Surface Mount	10 bits	0.25 LSB	0.5 LSB	16.5 V	16.5 V	4.5 V	-10.8 V	250 ns	Die
Analog Devices Inc./Maxim Integrated AD561KN										0.3 in	16-DIP 16-PDIP	7.62 mm			Through Hole
Analog Devices Inc./Maxim Integrated AD561SD	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel		Internal	0.3 in	16-CDIP	7.62 mm	125 °C	-55 °C	Through Hole	10 bits	0.25 LSB	0.5 LSB	16.5 V	16.5 V	4.5 V	-10.8 V	250 µs
Analog Devices Inc./Maxim Integrated AD561KD	Current - Unbuffered	R-2R	No	16.5 V	4.5 V	1 count	Parallel		Internal	0.3 in	16-CDIP	7.62 mm	70 °C	0 °C	Through Hole	10 bits	0.125 LSB	0.25 LSB	16.5 V	16.5 V	4.5 V	-10.8 V	250 µs
Analog Devices Inc./Maxim Integrated AD561SD/883B
