832 Series

Manufacturer: Preci-Dip

Catalog

CONN HEADER VERT 90POS 2MM

Part	Mounting Type	Termination	Fastening Type	Contact Length - Post [x]	Contact Length - Post [x]	Number of Positions	Voltage Rating	Contact Type	Overall Contact Length	Overall Contact Length	Insulation Color	Row Spacing - Mating	Row Spacing - Mating	Connector Type	Number of Positions Loaded	Contact Material	Contact Shape	Number of Rows [custom]	Contact Length - Mating	Contact Length - Mating	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Shrouding	Contact Finish - Post	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height	Insulation Height	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Number of Positions [custom]
Preci-Dip 832-80-090-10-001101	Through Hole	Solder	Push-Pull	0.114 in	2.9 mm	90	150 VDC	Male Pin	10 mm	0.394 in	Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin
Preci-Dip 832-80-038-30-001101	Surface Mount	Solder	Push-Pull			38	150 VDC	Male Pin			Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin
Preci-Dip 832-10-026-20-001101	Right Angle Through Hole	Solder	Push-Pull	0.126 "	3.2 mm	26	150 VDC	Male Pin			Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Gold	Gold	0.25 µm	10 µin	0.165 in	4.2 mm
Preci-Dip 832-80-086-10-001101	Through Hole	Solder	Push-Pull	0.114 in	2.9 mm	86	150 VDC	Male Pin	10 mm	0.394 in	Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin
Preci-Dip 832-10-064-20-001101	Right Angle Through Hole	Solder	Push-Pull	0.126 "	3.2 mm	64	150 VDC	Male Pin			Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Gold	Gold	0.25 µm	10 µin	0.165 in	4.2 mm
Preci-Dip 832-80-052-10-001101	Through Hole	Solder	Push-Pull	0.114 in	2.9 mm	52	150 VDC	Male Pin	10 mm	0.394 in	Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin
Preci-Dip 832-V3-026-12-002101	Through Hole	Solder	Push-Pull	0.122 in	3.1 mm	26	150 VDC	Male Pin	9.4 mm	0.37 in	Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.118 in	3 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin	Gold			0.268 in	6.8 mm	29.5 µin	0.75 µm
Preci-Dip 832-10-078-30-001101	Surface Mount	Solder	Push-Pull			78	150 VDC	Male Pin			Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Gold	Gold	0.25 µm	10 µin
Preci-Dip 832-10-084-10-001101	Through Hole	Solder	Push-Pull	0.114 in	2.9 mm		150 VDC	Male Pin	10 mm	0.394 in	Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Gold	Gold	0.25 µm	10 µin					84
Preci-Dip 832-80-018-20-001101	Right Angle Through Hole	Solder	Push-Pull	0.126 "	3.2 mm	18	150 VDC	Male Pin			Black	2 mm	0.079 in	Header	All	Brass	Circular	2	0.141 in	3.6 mm	3 A	-55 C	125 °C	0.079 "	2 mm	UL94 V-0	Unshrouded	Tin				0.165 in	4.2 mm
