ERNI VolTron 1000 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SRCP 6,20 2 M * SMD 137 E-HD 205 * * * J
| Part | Contact Shape | Contact Length - Mating | Contact Length - Mating | Contact Finish - Mating | Insulation Color | Insulation Height | Insulation Height | Contact Type | Insulation Material | Connector Type | Number of Positions Loaded | Style | Material Flammability Rating | Number of Positions | Number of Rows | Mounting Type | Shrouding | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Termination | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Current Rating (Amps) | Contact Material | Voltage Rating | Features | Pitch | Pitch | Contact Termination | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Square | 4.09 mm | 0.161 in | Gold | Orange | 9.4 mm | 0.37 in | Male Pin | Nylon 6/6 Polyamide (PA66) | Header | All | Board to Cable/Wire | UL94 V-0 | 2 | 1 | Surface Mount | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | ||||||||||
 TE Connectivity AMP Connectors | Square | 4.09 mm | 0.161 in | Gold | Orange | 5 mm | 0.197 " | Male Pin | Polyphthalamide (PPA) | Header | All | Board to Cable/Wire | UL94 V-0 | 2 | 1 | Right Angle Surface Mount | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | 157.5 Áin | 4 Ám | 5 A | Copper Alloy | 1000 VDC | Solder Retention | ||||
TE Connectivity AMP Connectors | Square | 4.09 mm | 0.161 in | Gold | Orange | 9.4 mm | 0.37 in | Male Pin | Nylon 6/6 Polyamide (PA66) | Header | All | Board to Cable/Wire | UL94 V-0 | 6 | 1 | Surface Mount | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | 157.5 Áin | 4 Ám | Board Guide Pick and Place Solder Retention | |||||||
 TE Connectivity AMP Connectors | Female Socket | Nylon 6/6 Polyamide (PA66) | Receptacle | 5 | 1 | Free Hanging (In-Line) | -40 C | 150 °C | Push-Pull | 0.244 " | 6.2 mm | Crimp | Black | |||||||||||||||||||||
 TE Connectivity AMP Connectors | Square | Gold | Orange | 5 mm | 0.197 " | Male Pin | Polyphthalamide (PPA) | Header | All | Board to Cable/Wire | UL94 V-0 | 5 | 1 | Right Angle Surface Mount | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | 157.5 Áin | 4 Ám | 5 A | Copper Alloy | 1000 VDC | Board Guide Solder Retention | ||||||
 TE Connectivity AMP Connectors | Square | 4.09 mm | 0.161 in | Gold | Black | 5 mm | 0.197 " | Male Pin | Polybutylene Terephthalate (PBT) | Header | All | Board to Board Cable | UL94 V-0 | 5 | 1 | Right Angle Through Hole | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | 25 µin | 0.63 µm | 0.5 A | Copper Alloy | Board Guide Solder Retention | |||||
 TE Connectivity AMP Connectors | Female Socket | Nylon 6/6 Polyamide (PA66) | Receptacle | 5 | 1 | Free Hanging (In-Line) | -40 C | 150 °C | Push-Pull | 0.244 " | 6.2 mm | Crimp | ||||||||||||||||||||||
 TE Connectivity AMP Connectors | Female Socket | Nylon 6/6 Polyamide (PA66) | Receptacle | 6 | 1 | Free Hanging (In-Line) | -40 C | 150 °C | Push-Pull | 0.244 " | 6.2 mm | Crimp | ||||||||||||||||||||||
 TE Connectivity AMP Connectors | Female Socket | Nylon 6/6 Polyamide (PA66) | Receptacle | 2 | 1 | Free Hanging (In-Line) | -40 C | 150 °C | Push-Pull | 0.244 " | 6.2 mm | Crimp | ||||||||||||||||||||||
 TE Connectivity AMP Connectors | Square | 4.09 mm | 0.161 in | Gold | Black | 5 mm | 0.197 " | Male Pin | Polyphthalamide (PPA) | Header | All | Board to Cable/Wire | UL94 V-0 | 2 | 1 | Right Angle Surface Mount | Shrouded - 4 Wall | Tin | 0.244 in | 6.2 mm | -40 C | 150 °C | Push-Pull | Solder | 0.5 A | Copper Alloy | 1000 VDC | Solder Retention |
