ZWS300 Series
Manufacturer: TDK Corporation
Beta
⌘K
AC/DC OPEN FRAME POWER SUPPLY (PSU), ACTIVE PFC, 1 OUTPUT, ADJUSTABLE, FIXED, 12 V
| Part | Mounting Type | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Approval Agency | Current - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Number of Outputs | Voltage - Isolation | Efficiency | Type | Features | Voltage - Output 1 | Applications | Power (Watts) | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output 1 [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 25 A | 70 °C | -10 °C | 1 | 3000 V | 89 % | Enclosed | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 12 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 8.4 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Open Frame | Adjustable Output DC Input Capable Load Sharing Remote On/Off Universal Input | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | 36 V | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 6.3 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Open Frame | Adjustable Output DC Input Capable Load Sharing Remote On/Off Universal Input | 48 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 8.4 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Enclosed | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | 36 V | |
TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 6.3 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Enclosed | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 48 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 8.4 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Open Frame | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | 36 V | |
TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 6.3 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Open Frame | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 48 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 6.3 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Enclosed | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 48 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 25 A | 70 °C | -10 °C | 1 | 3000 V | 89 % | Open Frame | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 12 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC | |
 TDK Corporation | Chassis Mount | 42 mm | 84 mm | 1.65 " | 180 mm | 7.09 in | 3.31 in | CE cURus TUV | 6.3 A | 70 °C | -10 °C | 1 | 3000 V | 88 % | Open Frame | Adjustable Output DC Input Capable Load Sharing PFC Universal Input | 48 V | ITE (Commercial) | 336 W | 300 W | 265 VAC | 85 VAC |
