MVE Series

Manufacturer: Chemi-Con

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SMD

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Mounting Type	Lifetime @ Temp.	Polarization	Operating Temperature [Min]	Operating Temperature [Max]	Tolerance	Voltage - Rated	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max)	Ripple Current @ Low Frequency	Applications	Capacitance	Height - Seated (Max) [Max]	Ripple Current @ High Frequency	Ratings	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Chemi-Con EMVE160ARA151MF80G	0.248 "	6.3 mm	0.26 in	6.6 mm	6.6 mm	0.26 in	Surface Mount	1000 Hrs	Polar	-40 C	105 ░C	20 %	16 V	Radial Can - SMD	0.303 in	7.7 mm	100 mA	General Purpose	150 µF
Chemi-Con EMVE500ARA102MMN0S	0.709 in	18 mm	0.748 in	19 mm	19 mm	0.748 in	Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	50 VDC	Radial Can - SMD	0.846 "		1.2 A	General Purpose	1000 µF	21.5 mm	1.8 A	AEC-Q200
Chemi-Con EMVE6R3ARA332MKG5S	0.492 in	12.5 mm					Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	6.3 VDC	Radial Can - SMD			850 mA	General Purpose	3.3 mF				16 mm	0.63 in
Chemi-Con EMVE630ARA470MHA0G	0.315 in	8 mm	0.327 in	8.3 mm	8.3 mm	0.327 in	Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	63 V	Radial Can - SMD	0.394 in		170 mA	General Purpose	47 µF	10 mm
Chemi-Con EMVE630ARA221MKE0S	0.492 in	12.5 mm					Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	63 V	Radial Can - SMD	0.531 in		470 mA	General Purpose	220 µF	13.5 mm
Chemi-Con EMVE6R3ARA222MLH0S	0.63 in	16 mm	0.669 in	17 mm	17 mm	0.669 in	Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	6.3 VDC	Radial Can - SMD			840 mA	General Purpose	2.2 mF		907.2 mA	AEC-Q200	16.5 mm	0.65 in
Chemi-Con EMVE500ARA221MJA0G	0.394 in	10 mm	0.406 in	10.3 mm	10.3 mm	0.406 "	Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	50 VDC	Radial Can - SMD	0.394 in		375 mA	General Purpose	220 µF	10 mm
Chemi-Con EMVE160ARA222MMH0S	0.709 in	18 mm	0.748 in	19 mm	19 mm	0.748 in	Surface Mount	2000 Hrs	Polar	-40 C	105 ░C	20 %	16 V	Radial Can - SMD			1 A	General Purpose	2.2 mF		1.08 A	AEC-Q200	16.5 mm	0.65 in
