RAYCHEM VOLINSU EVDW Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
EVDW-19/6-3-STK
| Part | Material | Features | Length [x] | Length [x] | Shrinkage Ratio | Inner Diameter - Supplied [diameter] | Inner Diameter - Supplied [diameter] | Recovered Wall Thickness | Recovered Wall Thickness | Inner Diameter - Recovered [diameter] | Inner Diameter - Recovered [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Spool Size [x] | Spool Size [x] | Length | Length | Length | Type | Inner Diameter - Supplied | Shelf Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Flame Retardant | 4 ft | 1.22 m | 3 to 1 | 0.748 in | 19 mm | 2.26 mm | 0.089 in | 5.99 mm | 0.236 in | -40 C | 105 ░C | ||||||||
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Abrasion Resistant Flame Retardant | 3 to 1 | 0.354 in | 8.99 mm | 1.4 mm | 0.055 in | 3 mm | 0.118 in | -40 C | 105 ░C | 200 m | 656.2 ft | Enter Number of Meters in Order Quantity | 656.2 ft | 200 m | Tubing Flexible | ||||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Abrasion Resistant Flame Retardant | 3 to 1 | 1.575 " | 2.54 mm | 0.1 in | 13 mm | 0.512 in | -40 C | 105 ░C | 200 m | 656.2 ft | Enter Number of Meters in Order Quantity | 196.8 ' | 60 m | Tubing Flexible | 40.01 mm | ||||
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Abrasion Resistant Flame Retardant | 3 to 1 | 0.472 in | 11.99 mm | 1.78 mm | 0.07 in | 3.99 mm | 0.157 " | -40 C | 105 ░C | 200 m | 656.2 ft | Enter Number of Meters in Order Quantity | 656.2 ft | 200 m | Tubing Flexible | ||||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Abrasion Resistant Flame Retardant | 3 to 1 | 0.945 " | 24 mm | 2.54 mm | 0.1 in | 8 mm | 0.315 in | -40 C | 105 ░C | 80 m | 262.5 ft | Enter Number of Meters in Order Quantity | 262.5 ' | 80 m | Tubing Flexible | 60 Months | |||
 TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Flame Retardant | 4 ft | 1.22 m | 3 to 1 | 0.472 in | 11.99 mm | 1.78 mm | 0.07 in | 3.99 mm | 0.157 " | -40 C | 105 ░C | ||||||||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Flame Retardant | 4 ft | 1.22 m | 3 to 1 | 1.575 " | 2.54 mm | 0.1 in | 13 mm | 0.512 in | -40 C | 105 ░C | 40.01 mm | ||||||||
TE Connectivity AMP Connectors | Polyolefin (PO) Irradiated | Abrasion Resistant Flame Retardant | 3 to 1 | 0.748 in | 19 mm | 2.26 mm | 0.089 in | 5.99 mm | 0.236 in | -40 C | 105 ░C | 200 m | 656.2 ft | Enter Number of Meters in Order Quantity | 656.2 ft | 200 m | Tubing Flexible |
