FGS.2F Series

Manufacturer: LEMO

Catalog

CONN PLUG FMALE 19POS GOLD CRIMP

Part	Cable Opening	Cable Opening	Current Rating (Amps)	Color	Shielding	Termination	Contact Finish - Mating	Shell Finish	Shell Material	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Positions	Applications	Contact Material	Insert Material	Orientation	Material Flammability Rating	Primary Material	Ingress Protection	Fastening Type	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Shell Size - Insert
LEMO FGS.2F.319.XLM	0.551 "	14 mm	5 A	Gray	Shielded	Crimp	Gold	Nickel	Aluminum Alloy	Free Hanging (In-Line)	1.5 Ám	59 Áin	19	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-15 °C	200 °C	319
LEMO FGS.2F.308.XLM	0.551 "	14 mm	10 A	Gray	Shielded	Crimp	Gold	Nickel	Aluminum Alloy	Free Hanging (In-Line)	1.5 Ám	59 Áin	8	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-15 °C	200 °C	308
LEMO FGS.2F.312.XLM	0.551 "	14 mm	7 A	Gray	Shielded	Crimp	Gold	Nickel	Aluminum Alloy	Free Hanging (In-Line)	1.5 Ám	59 Áin	12	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-15 °C	200 °C	312
LEMO FGS.2F.319.CLM	0.551 "	14 mm	5 A	Silver	Shielded	Crimp	Gold	Chrome	Brass	Free Hanging (In-Line)	1.5 Ám	59 Áin	19	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-55 C	200 °C	319
LEMO FGS.2F.319.XLMS	0.551 "	14 mm	5 A	Gray	Shielded	Crimp	Gold	Nickel	Aluminum Alloy	Free Hanging (In-Line)	1.5 Ám	59 Áin	19	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-15 °C	200 °C	319
LEMO FGS.2F.310.XLM	0.551 "	14 mm	8 A	Gray	Shielded	Crimp	Gold	Nickel	Aluminum Alloy	Free Hanging (In-Line)	1.5 Ám	59 Áin	10	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-15 °C	200 °C	310
LEMO FGS.2F.312.CLM	0.551 "	14 mm	7 A	Silver	Shielded	Crimp	Gold	Chrome	Brass	Free Hanging (In-Line)	1.5 Ám	59 Áin	12	Aerospace	Bronze	Polyetheretherketone (PEEK)	S	UL94 V-0	Metal	IP67 - Dust Tight Waterproof	Push-Pull	Plug Female Sockets	-55 C	200 °C	312
