FAA.2S Series
Manufacturer: LEMO
Beta
⌘K
CONN TRIAX PLUG STR 95OHM SOLDER
| Part | Dielectric Material | Center Contact Plating | Body Material | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Mating Cycles | Shield Termination | Connector Type | Ingress Protection | Fastening Type | Mounting Type | Contact Termination | Mounting Feature | Housing Color | Number of Ports | Color | Number of Positions | Current Rating (Amps) | Shell Finish | Primary Material | Orientation | Shell Size - Insert | Insert Material | Shielding | Contact Finish - Mating | Contact Material | Shell Material | Material Flammability Rating | Includes | Center Contact Material | Connector Style | Cable Group | Impedance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LEMO | Polyetheretherketone (PEEK) | Gold | Brass | Chrome | -55 C | 250 °C | 5000 | Solder | Plug Male Pin | IP50 - Dust Protected | Push-Pull | Panel Mount | Solder Cup | Bulkhead - Rear Side Nut | Silver | 1 | ||||||||||||||||||
LEMO | -55 C | 250 °C | Plug Male Pins | IP50 - Dust Protected | Push-Pull | Panel Mount | Bulkhead - Rear Side Nut | Silver | 1 | 40 A | Chrome | Metal | Keyed | 140 | Polytetrafluoroethylene (PTFE) | Shielded | Gold | Brass | Brass | |||||||||||||||
LEMO | -55 C | 250 °C | Plug Female Sockets and Male Pins | IP50 - Dust Protected | Push-Pull | Panel Mount | Bulkhead - Rear Side Nut | Silver | 6 | 12 Amps | Chrome | Metal | Keyed | 306 | Polyetheretherketone (PEEK) | Shielded | Gold | Brass Bronze | Brass | UL94 V-0 | ||||||||||||||
 LEMO | Polytetrafluoroethylene (PTFE) | Gold | Brass | Chrome | -55 C | 200 °C | 1000 | Solder | Plug Male Pin | IP50 - Dust Protected | Push-Pull | Panel Mount | Solder Cup | Bulkhead - Rear Side Nut | Silver | 1 | 1 Connector 1 Nut | Brass | Triaxial | 8232A 9222 Belden 8215 RG-174 | 50 Ohms |
