POWER INDUCTORS - SMD 963-LSXBD6060MKT220M RPLCMT PN 22UH 6060 20% LOW PROFILE

Part	Shielding	Inductance Frequency - Test	Tolerance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Frequency - Self Resonant	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Current - Saturation (Isat)	Current Rating (Amps)	Inductance	Material - Core	Type	Mounting Type	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	DC Resistance (DCR) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	DC Resistance (DCR)	Height - Seated (Max) [Max]	Height - Seated (Max)
Taiyo Yuden NR6012T220ME	Shielded	100 kHz	20 %	1.2 mm	0.047 "	12 MHz	0.236 "	6 mm	0.236 in	6 mm	760 mA	0.63 A	22 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	636 mOhm
Taiyo Yuden NR6020T4R7N	Semi-Shielded	100 kHz	30 %			43 MHz	0.236 "	6 mm	0.236 in	6 mm	2.4 A	2 A	4.7 ÁH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	69.6 mOhm	0.079 in	2 mm
Taiyo Yuden NR5040T3R3N	Semi-Shielded	100 kHz	30 %			32 MHz	0.193 in	4.9 mm	0.193 in	4.9 mm	3.8 A	3.3 A	3.3 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C		4.1 mm		35.1 mOhm	0.161 in
Taiyo Yuden NR3010T470M	Shielded	100 kHz	20 %			17 MHz	0.118 in	3 mm	0.118 "	3 mm	220 mA	235 mA	47 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	2.46 Ohm	1 mm			0.039 in
Taiyo Yuden NR6028T680M	Semi-Shielded Shielded	100 kHz	20 %			5 MHz	0.236 "	6 mm	0.236 in	6 mm	760 mA	770 mA	68 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	546 mOhm
Taiyo Yuden NR8040T220M	Semi-Shielded	100 kHz	20 %			13 MHz	0.315 in	8 mm	0.315 in	8 mm	2.2 A	2.2 A	22 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	85.8 mOhm				0.157 in	4 mm
Taiyo Yuden NR3015T1R0N	Semi-Shielded	100 kHz	30 %			100 MHz	0.118 in	3 mm	0.118 "	3 mm	2.1 A	2.1 A	1 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	36 mOhm				0.059 "	1.5 mm
Taiyo Yuden NR4018T221M	Shielded	100 kHz	20 %			4 MHz	0.157 "	4 mm	0.157 in	4 mm	270 mA	0.17 A	220 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	4.8 Ohm	1.8 mm			0.071 in
Taiyo Yuden NR4012T1R0N	Shielded	100 kHz	30 %	1.2 mm	0.047 "	131 MHz	0.157 "	4 mm	0.157 in	4 mm	2.5 A	1.5 A	1 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C				72 mOhm
Taiyo Yuden NR3015T220M	Semi-Shielded	100 kHz	20 %			20 MHz	0.118 in	3 mm	0.118 "	3 mm	470 mA	470 mA	22 µH	Ferrite	Drum Core Wirewound	Surface Mount	Nonstandard	120 °C	-25 °C	624 mOhm				0.059 "	1.5 mm
