Reed Relays HV RELAYS
Reed Relays HV RELAYS
| Part | Contact Form | Operating Temperature [Max] | Operating Temperature [Min] | Contact Rating (Current) | Coil Current | Coil Voltage | Termination Style | Coil Type | Must Operate Voltage | Must Release Voltage | Operate Time | Switching Voltage [Max] | Contact Material | Release Time | Mounting Type | Coil Resistance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 15.5 mA | 24 VDC | PC Pin | Non Latching | 19 VDC | 4 VDC | 1 ms | 300 VAC 350 VDC | Rhodium (Rh) | 0.5 ms | Through Hole | |
 Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 41.7 mA | 5 VDC | PC Pin | Non Latching | 4 VDC | 1 VDC | 1 ms | 300 VAC 350 VDC | Rhodium (Rh) | 0.5 ms | Through Hole | |
 Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 41.7 mA | 5 VDC | PC Pin | Non Latching | 4 VDC | 1 VDC | 1 ms | 1000 VAC 1000 VDC | Rhodium (Rh) | 0.5 ms | Through Hole | 120 Ohms |
Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 16 mA | 12 VDC | PC Pin | Non Latching | 9.6 VDC | 2 VDC | 1 ms | 1000 VAC 1000 VDC | Rhodium (Rh) | 0.5 ms | Through Hole | |
 Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 15.5 mA | 24 VDC | PC Pin | Non Latching | 19 VDC | 4 VDC | 1 ms | 1000 VAC 1000 VDC | Rhodium (Rh) | 0.5 ms | Through Hole | 1.55 kOhms |
Sensata-Crydom | SPST-NO (1 Form A) | 85 °C | -40 C | 1 A | 16 mA | 12 VDC | PC Pin | Non Latching | 9.6 VDC | 2 VDC | 1 ms | 300 VAC 350 VDC | Rhodium (Rh) | 0.5 ms | Through Hole |
