Liquid Level Sensors LLS
Liquid Level Sensors LLS
| Part | Material - Housing & Prism | Type | Output Type | Mounting Type | Output Configuration | Minimum Liquid Specific Gravity [Min] | Switch Actuation Level | Switch Actuation Level | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Current | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Polyvinylidene Fluoride (PVDF) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.85 | 0.49 in | 12.5 mm | -10 °C | 105 ░C | 120 VDC 240 VAC | 600 mA | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.65 | -20 ░C | 100 °C | 300 VDC 300 VAC | 1 A | |||
 Sensata-Crydom | Polyvinylidene Fluoride (PVDF) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.85 | 0.49 in | 12.5 mm | -10 °C | 105 ░C | 120 VDC 240 VAC | 600 mA | |
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | Male 1/8" NPT | SPST-NC/NO | 0.65 | -20 ░C | 100 °C | 120 VDC 240 VAC | 600 mA | 3.18 mm | ||
 Sensata-Crydom | Nylon | Liquid | Switch (Single Float) | Male 1/8" NPT | SPST-NC/NO | 0.8 | 0.886 " | 22.5 mm | 300 VDC 300 VAC | 1 A | 3.18 mm | ||
 Sensata-Crydom | Polyphenylene Sulphide (PPS) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.85 | 0.374 in 0.807 in | 9.5 mm 20.5 mm | -10 °C | 120 °C | 120 VDC 240 VAC | 600 mA | |
 Sensata-Crydom | Polyvinylidene Fluoride (PVDF) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.49 in | 12.5 mm | -10 °C | 105 ░C | 300 VDC 300 VAC | 1 A | ||
 Sensata-Crydom | Polypropylene (PP) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.65 | -20 ░C | 100 °C | 120 VDC 240 VAC | 600 mA | |||
 Sensata-Crydom | Nylon | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.8 | 0.886 " | 22.5 mm | 120 VDC 240 VAC | 600 mA | |||
 Sensata-Crydom | Polyphenylene Sulphide (PPS) | Liquid | Switch (Single Float) | M12x1.75 Thread Panel Mount | SPST-NC/NO | 0.85 | -10 °C | 120 °C | 300 VDC 300 VAC | 1 A |
