306-028 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 28 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Gender | Read Out | Number of Rows [custom] | Card Type | Contact Material | Color | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Pitch | Pitch | Mounting Type | Contact Finish | Flange Feature | Contact Type | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount Through Hole | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 28 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Through Hole | Gold | Cantilever | 28 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder Eyelet(s) | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 28 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Through Hole | Gold | Flush Mount Top Opening Unthreaded | Cantilever | 28 | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount Through Hole | Gold | Floating Bobbin Flush Mount | Cantilever | 28 | 0.116 " | 2.95 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount Through Hole | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 28 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount Through Hole | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 28 | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Through Hole | Gold | Flush Mount Top Opening Unthreaded | Cantilever | 28 | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Through Hole | Gold | Flush Mount Top Opening Unthreaded | Cantilever | 28 | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Solder | Female | Dual | 2 | Non Specified - Dual Edge | Copper Alloy | Green | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 56 | 3.96 mm | 0.156 in | Panel Mount Through Hole | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 28 | Card Guides |
