292230 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

1 TIN -30℃~+105℃ BRASS VERTICAL WELDING SMD WIRE TO BOARD CONNECTOR ROHS

Part	Applications	Contact Length - Mating [custom]	Contact Length - Mating [custom]	Termination	Shrouding	Insulation Color	Mounting Type	Number of Positions Loaded	Contact Type	Contact Finish - Post	Material Flammability Rating	Style	Number of Positions	Insulation Material	Contact Shape	Fastening Type	Current Rating (Amps)	Insulation Height	Insulation Height [z]	Number of Rows	Operating Temperature [Min]	Operating Temperature [Max]	Features	Voltage Rating	Contact Material	Connector Type	Number of Positions
TE Connectivity Raychem Cable Protection 5-292230-6	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	6	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 292230-9	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Beige	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	9	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 292230-5	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Beige	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire		Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 5-292230-5	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire		Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 292230-8	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Beige	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	8	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 6-292230-7	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire		Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 6-292230-6	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire		Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header	16
TE Connectivity Raychem Cable Protection 6-292230-3	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	13	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 1-292230-5	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Beige	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	15	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
TE Connectivity Raychem Cable Protection 5-292230-7	General Purpose	2.4 mm	0.094 in	Solder	Shrouded - 4 Wall	Black	Surface Mount	All	Male Pin	Tin	UL94 V-0	Board to Cable/Wire	7	Glass Filled Nylon Polyamide (PA)	Square	Detent Lock	Varies by Wire Gauge	6.91 mm	0.272 "	1	-30 ░C	105 ░C	Board Guide	50 VAC	Brass	Header
