1825399 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
PUSHBUTTON SWITCH, DPDT, LATCHED, SOLDER TERMINAL, THROUGH HOLE-STRAIGHT
| Part | Mounting Type | Circuit | Actuator Type | Actuator Marking | Termination Style | Electrical Life | Switch Function | Panel Cutout Dimensions [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Features | Voltage Rating - AC | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Panel Mount Rear | DPDT | Plunger for Cap | No Marking | PC Pin | 50000 Cycles | On-On | 0.25 in | -15 °C | 70 °C | 3 A | Epoxy Sealed Terminals | 125 V | Standard |
