638-M44 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB HD RCPT 44P VERT SLDR
| Part | Dielectric Material | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Mounting Type | Current Rating (Amps) | Shell Size, Connector Layout | Contact Finish | Number of Rows [custom] | Number of Positions | Connector Type | Contact Type | Material Flammability Rating | Features | Termination | Flange Feature | Flange Feature | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Through Hole | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Solder | Housing/Shell | 4-40 | D-Sub High Density | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Through Hole | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Solder | Housing/Shell (Unthreaded) | D-Sub High Density | 15 µin | 0.38 µm | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Through Hole | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Board Lock Shielded | Solder | 4-40 | D-Sub High Density | 30 Áin | 0.76 Ám | Nickel Plated Steel | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Free Hanging (In-Line) | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Housing/Shell (Unthreaded) | D-Sub High Density | 15 µin | 0.38 µm | Nickel Plated Steel | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Free Hanging (In-Line) | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Board Lock Shielded | 4-40 | D-Sub High Density | 30 Áin | 0.76 Ám | Nickel Plated Steel | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Free Hanging (In-Line) | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Housing/Shell (Unthreaded) | D-Sub High Density | 30 Áin | 0.76 Ám | Nickel Plated Steel | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Through Hole | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Solder | Housing/Shell (Unthreaded) | D-Sub High Density | 30 Áin | 0.76 Ám | Nickel Plated Steel | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Free Hanging (In-Line) | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Board Lock Shielded | 4-40 | D-Sub High Density | Nickel Plated Steel | Flash | ||||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Through Hole | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Solder | Board Side (4-40) | D-Sub High Density | Nickel Plated Steel | Flash | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | -55 C | 125 °C | Black | Free Hanging (In-Line) | 5 A | 3 | Gold | 3 | 44 | Receptacle Female Sockets | Signal | UL94 V-0 | Shielded | Housing/Shell (Unthreaded) | D-Sub High Density | Flash |
