845-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 19POS 0.100
| Part | Termination Rows | Material - Insulation | Gender | Number of Positions/Bay/Row | Read Out | Mounting Type | Color | Contact Type | Number of Positions | Card Type | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Termination | Card Thickness [Max] | Card Thickness [Min] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Right Angle Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Right Angle Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 19 | Single | Through Hole | Green | Cantilever | 19 | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 125 °C | -40 C | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
