2043 Series

Manufacturer: Oupiin

Catalog

PCB SOCKET, DOUBLE ROW, 24 PIN,

Part	Insulation Material	Contact Shape	Contact Material	Contact Finish Thickness - Post	Contact Type	Insulation Height	Insulation Height	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Finish Thickness - Mating	Pitch - Mating	Pitch - Mating	Number of Positions	Number of Rows [custom]	Termination	Contact Finish - Mating	Current Rating (Amps)	Material Flammability Rating	Mounting Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish - Post	Fastening Type	Number of Positions Loaded	Features	Contact Length - Post [x]	Contact Length - Post [x]	Number of Rows
Oupiin 2043-2X12G00DNT-P	Plastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	24	2	Solder	Gold	2 A	UL94 V-0	Surface Mount	0.1 in	2.54 mm	Gold	Push-Pull	All	Board Guide Pick and Place
Oupiin 2043-1X16G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	16		Solder	Gold	2 A	UL94 V-0	Through Hole			Gold	Push-Pull	All		0.126 "	3.2 mm	1
Oupiin 2043-1X10G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	10		Solder	Gold	2 A	UL94 V-0	Through Hole			Gold	Push-Pull	All		0.126 "	3.2 mm	1
Oupiin 2043-2X16G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm		2	Solder	Gold	2 A	UL94 V-0	Through Hole	0.1 in	2.54 mm	Gold	Push-Pull	All		0.126 "	3.2 mm
Oupiin 2043-2X03G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	6	2	Solder	Gold	2 A	UL94 V-0	Through Hole	0.1 in	2.54 mm	Gold	Push-Pull	All		0.126 "	3.2 mm
Oupiin 2043-2X05G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	10	2	Solder	Gold	2 A	UL94 V-0	Through Hole	0.1 in	2.54 mm	Gold	Push-Pull	All		0.126 "	3.2 mm
Oupiin 2043-2X25G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	50	2	Solder	Gold	2 A	UL94 V-0	Through Hole	0.1 in	2.54 mm	Gold	Push-Pull	All		0.126 "	3.2 mm
Oupiin 2043-2X06G00SA	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	12	2	Solder	Gold	2 A	UL94 V-0	Through Hole	0.1 in	2.54 mm	Gold	Push-Pull	All		0.126 "	3.2 mm
Oupiin 2043-2X04G00SB	Glass Filled Polyester Thermoplastic	Square	Copper Alloy	Flash	Female Socket	0.28 in	7.1 mm	-55 C	105 ░C	Socket	Flash	0.1 "	2.54 mm	8		Solder	Gold	2 A	UL94 V-0	Through Hole			Gold	Push-Pull	All		0.126 "	3.2 mm	1
