337-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 56 CONTACTS, THROUGH HOLE MOUNT, RIGHT ANGLE
| Part | Material - Insulation | Termination Rows [custom] | Contact Material | Gender | Mounting Type | Read Out | Color | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Rows [custom] | Pitch | Pitch | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Right Angle Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Board Edge Straddle Mount | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Card Extender | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Board Edge Straddle Mount | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge | 4-40 Threaded Insert Top Mount Opening | Card Extender Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 2 | Copper Alloy | Female | Through Hole | Dual | Green | 28 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | -40 C | 105 ░C | 56 | Wire Wrap | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | Non Specified - Dual Edge |
