2532HS Series
Manufacturer: ECS Inc.
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
STANDARD CLOCK OSCILLATORS ECS-2532HS,OSC XO 44.000MHZ CMOS SMD,3.3V,+/-10PPM,-40+/-C - 85+/-C,10MA,SURFACE MOUNT,0.126" L X 0.098" W (3.20MM X 2.50MM),0.039" (1.00MM)
| Part | Package Length | Package Name | Package Width | Current - Supply (Disable) (Max) | Frequency Stability | Current - Supply (Max) | Function | Frequency | Height - Seated (Max) | Voltage - Supply | Mounting Type | Type | Base Resonator | Output | Operating Temperature (Min) | Operating Temperature (Max) | Size / Dimension Width | Size / Dimension Length | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ECS Inc. | 3.2 mm | 4-SMD 4-VDFN | 2.5 mm | 10 µA | 10 ppm | 10 mA | Disable Enable | 44 MHz | 0.043 in | 3.3 V | Surface Mount | XO (Standard) | Crystal | CMOS | -40 °C | 85 °C | 0.098 in | 0.126 in | 4-SMD No Lead |
 ECS Inc. | 3.2 mm | 4-SMD | 2.5 mm | 10 µA | 10 ppm | 10 mA | Disable Enable | 26 MHz | 0.043 in | 3.3 V | Surface Mount | XO (Standard) | Crystal | CMOS | -40 °C | 85 °C | 0.098 in | 0.126 in | 4-SMD No Lead |
 ECS Inc. | 3.2 mm | 4-SMD | 2.5 mm | 10 µA | 10 ppm | 10 mA | Disable Enable | 25 MHz | 0.043 in | 3.3 V | Surface Mount | XO (Standard) | Crystal | CMOS | -40 °C | 85 °C | 0.098 in | 0.126 in | 4-SMD No Lead |
