BLF6G20 Series

Catalog

RF MOSFET LDMOS 28V SOT539A

Part	Voltage - Test	Configuration	Gain	Power - Output	Package / Case	Frequency [Min]	Frequency [Max]	Current - Test	Supplier Device Package	Mounting Type	Voltage - Rated	Current Rating (Amps)
Ampleon USA Inc. BLF6G20-230PRN,112	28 V	Common Source Dual	17.5 dBi	65 W	SOT-539A	1.8 GHz	1.88 GHz	2 A	SOT539A	Chassis Mount	65 V
Ampleon USA Inc. BLF6G20-230PRN,118	28 V	Common Source Dual	17.5 dBi	65 W	SOT-539A	1.8 GHz	1.88 GHz	2 A	SOT539A	Chassis Mount	65 V
Ampleon USA Inc. BLF6G20S-45,112	28 V		19.2 dB	2.5 W	SOT-608B	1.8 GHz	1.88 GHz	360 mA	CDFM2	Chassis Mount	65 V	13 A
Ampleon USA Inc. BLF6G20-45,112	28 V		19.2 dB	2.5 W	SOT-608A	1.8 GHz	1.88 GHz	360 mA	CDFM2	Chassis Mount	65 V	13 A
Ampleon USA Inc. BLF6G20S-45,118	28 V		19.2 dB	2.5 W	SOT-608B	1.8 GHz	1.88 GHz	360 mA	CDFM2	Chassis Mount	65 V	13 A
Ampleon USA Inc. BLF6G20LS-140,112	28 V		16.5 dBi	35.5 W	SOT-502B	1.93 GHz	1.99 GHz	1 A	SOT502B	Chassis Mount	65 V	39 A
Ampleon USA Inc. BLF6G20-75,112	28 V		19 dB	29.5 W	SOT-502A	1.93 GHz	1.99 GHz	550 mA	SOT502A	Chassis Mount	65 V	18 A
Ampleon USA Inc. BLF6G20-180PN,112	32 V	Common Source Dual	18 dBi	50 W	SOT-539A	1.8 GHz	1.88 GHz	1.6 A	SOT539A	Chassis Mount	65 V
Ampleon USA Inc. BLF6G20LS-110,112	28 V		19 dB	25 W	SOT-502B	1.93 GHz	1.99 GHz	900 mA	SOT502B	Chassis Mount	65 V	29 A
Ampleon USA Inc. BLF6G20LS-75,112	28 V		19 dB	29.5 W	SOT-502B	1.93 GHz	1.99 GHz	550 mA	SOT502B	Chassis Mount	65 V	18 A
