PEC23 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 23POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Length - Post [custom]	Contact Length - Post [custom]	Material Flammability Rating	Shrouding	Contact Length - Mating	Contact Length - Mating	Pitch - Mating	Pitch - Mating	Insulation Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Termination	Number of Positions	Connector Type	Insulation Color	Fastening Type	Insulation Height	Insulation Height	Number of Rows	Mounting Type	Contact Finish - Post	Contact Material	Style	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Contact Shape	Contact Type	Number of Positions Loaded	Contact Length - Post	Contact Length - Post	Number of Rows [custom]	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Overall Contact Length [x]	Overall Contact Length [x]	Overall Contact Length	Insulation Height [z]	Insulation Height [z]
Sullins Connector Solutions PEC23SGBN	2.54 µm	100 µin	5.08 mm	0.2 "	UL94 V-0	Unshrouded	8.08 mm	0.318 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	3.56 mm	0.14 in	1	Right Angle Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All
Sullins Connector Solutions PEC23SBDN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	3.56 mm	0.14 in	1	Right Angle Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	10.16 mm	0.4 in
Sullins Connector Solutions PEC23DAGN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	46	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in		Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	18.29 mm	0.72 "	2	26.67 mm	1.05 in	0.1 in	2.54 mm
Sullins Connector Solutions PEC23SADN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in	1	Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	10.67 mm	0.42 in						19.05 mm	0.75 in
Sullins Connector Solutions PEC23SFCN	2.54 µm	100 µin			UL94 V-0	Unshrouded	8.08 mm	0.318 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in	1	Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	8.13 mm	0.32 in		18.75 mm						0.738 in
Sullins Connector Solutions PEC23SAFN	2.54 µm	100 µin	15.75 mm	0.62 "	UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in	1	Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All				24.13 mm	0.95 in
Sullins Connector Solutions PEC23DBEN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	46	Header Breakaway	Black	Push-Pull				Right Angle Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	12.7 mm	0.5 "	2			0.1 in	2.54 mm				6.1 mm	0.24 in
Sullins Connector Solutions PEC23SBCN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	23	Header Breakaway	Black	Push-Pull	3.56 mm	0.14 in	1	Right Angle Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	7.62 mm	0.3 in
Sullins Connector Solutions PEC23DAAN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	46	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in		Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	3.05 mm	0.12 in	2			0.1 in	2.54 mm	11.43 mm	0.45 in
Sullins Connector Solutions PEC23DAEN	2.54 µm	100 µin			UL94 V-0	Unshrouded	5.84 mm	0.23 in	0.1 "	2.54 mm	Polybutylene Terephthalate (PBT)	100 çin	2.54 çm	Solder	46	Header Breakaway	Black	Push-Pull	2.54 mm	0.1 in		Through Hole	Tin	Phosphor Bronze	Board to Board Cable	3 A	-65 ░C	125 °C	Square	Male Pin	All	13.21 mm	0.52 in	2	21.59 mm	0.85 in	0.1 in	2.54 mm
