poscap-tpe Series

Manufacturer: Panasonic Electronic Components

Catalog

TANTALUM POLYMER CAPACITOR, 470 ΜF, ± 20%, 6.3 V, D4, 0.018 OHM, 2917 [7343 METRIC]

Part	Height - Seated (Max)	Height - Seated (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance	Package / Case	Features	ESR (Equivalent Series Resistance)	Tolerance	Voltage - Rated	Lifetime @ Temp.	Manufacturer Size Code	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Mounting Type	Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Package / Case	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Panasonic Electronic Components 6TPE470MI	4 mm	0.157 in	-55 C	105 ░C	470 µF	2917 (7343 Metric)	General Purpose	18 mOhm	20 %	6.3 VDC	2000 Hrs	D4	0.169 "	7.3 mm	0.287 "	4.3 mm	Surface Mount	Molded
Panasonic Electronic Components 2R5TPE330MI			-55 C	105 ░C	330 µF	2917 (7343 Metric)	General Purpose	18 mOhm	20 %	2.5 V	2000 Hrs	D2E	0.169 "	7.3 mm	0.287 "	4.3 mm	Surface Mount	Molded	0.079 in	2 mm
Panasonic Electronic Components ETPE330MIB			-55 C	105 ░C	330 µF	1411		18 mOhm	20 %	2.5 V	1000 Hrs	B2	0.11 "	3.5 mm	0.138 in	2.8 mm	Surface Mount	Molded	0.079 in	2 mm	3528 Metric
Panasonic Electronic Components 6TPE330MIL			-55 C	105 ░C	330 µF	2917 (7343 Metric)	General Purpose	18 mOhm	20 %	6.3 VDC	2000 Hrs	D3L	0.169 "	7.3 mm	0.287 "	4.3 mm	Surface Mount	Molded				0.118 "	3 mm
Panasonic Electronic Components 4TPE150MAZB			-55 C	105 ░C	150 µF	1411	General Purpose	35 mOhm	20 %	4 V	1000 Hrs	B2	0.11 "	3.5 mm	0.138 in	2.8 mm	Surface Mount	Molded	0.079 in	2 mm	3528 Metric
Panasonic Electronic Components 8TPE100MAZB			-55 C	105 ░C	100 µF	1411	General Purpose	35 mOhm	20 %	8 V	1000 Hrs	B2	0.11 "	3.5 mm	0.138 in	2.8 mm	Surface Mount	Molded	0.079 in	2 mm	3528 Metric
