820B Series
Manufacturer: NorComp Inc.
Beta
⌘K
CIRCULAR CONNECTOR, QUIK-LOQ 820B SERIES, PANEL MOUNT RECEPTACLE, 5 CONTACTS, SOLDER SOCKET
| Part | Contact Finish - Mating | Insert Material | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Feature | Number of Positions | Orientation | Voltage Rating | Primary Material | Shell Material | Shielding | Color | Ingress Protection | Mounting Type | Fastening Type | Connector Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material | Shell Finish | Current Rating (Amps) | Applications | Termination | Features | Backshell Material, Plating | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Cable Opening [Min] | Cable Opening | Cable Opening |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front or Rear Side Nut | 5 | Keyed | 280 V | Metal | Brass | Shielded | Silver | IP50 - Dust Protected | Panel Mount | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 6.5 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | |||||||||
NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front Side Nut | Keyed | 400 V | Metal | Brass | Shielded | Silver | IP50 - Dust Protected | Panel Mount Right Angle Through Hole | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 8 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Solder | |||||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | 6 | Keyed | 280 V | Metal | Brass | Shielded | Black Silver | IP50 - Dust Protected | Free Hanging (In-Line) | Push-Pull | Plug Male Pins | 7 µin | 0.178 µm | Copper Alloy | Nickel | 2.5 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Backshell Strain Relief | Brass Chrome | 3.2 mm | 0.126 in | 0.098 in | 2.5 mm | ||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front or Rear Side Nut | 2 | Keyed | 430 V | Metal | Brass | Shielded | Silver | IP50 - Dust Protected | Panel Mount | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 10 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | |||||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front Side Nut | 4 | Keyed | 280 V | Metal | Brass | Shielded | Silver | IP50 - Dust Protected | Panel Mount Through Hole | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 7 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Solder | ||||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front Side Nut | Keyed | 400 V | Metal | Brass | Shielded | Black Silver | IP50 - Dust Protected | Panel Mount Right Angle Through Hole | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 8 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Solder | Board Guide | ||||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | 2 | Keyed | 430 V | Metal | Brass | Shielded | Black Silver | IP50 - Dust Protected | Free Hanging (In-Line) | Push-Pull | Plug Male Pins | 7 µin | 0.178 µm | Copper Alloy | Nickel | 10 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Backshell Strain Relief | Brass Chrome | 0.205 in 5.2 mm | 0.169 " 4.3 mm | ||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Bulkhead - Front Side Nut | 9 | Keyed | 200 V | Metal | Brass | Shielded | Silver | IP50 - Dust Protected | Panel Mount Right Angle Through Hole | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 2 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Solder | ||||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | 5 | Keyed | 280 V | Metal | Brass | Shielded | Black Silver | IP50 - Dust Protected | Free Hanging (In-Line) | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 6.5 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Backshell Strain Relief | Brass Chrome | 0.205 in 5.2 mm | 0.169 " 4.3 mm | ||||||
 NorComp Inc. | Gold | Polyphenylene Sulfide (PPS) | -40 C | 200 °C | Keyed | 400 V | Metal | Brass | Shielded | Black Silver | IP50 - Dust Protected | Free Hanging (In-Line) | Push-Pull | Receptacle Female Sockets | 7 µin | 0.178 µm | Copper Alloy | Nickel | 8 A | Industrial Instrumentation Medical Telecommunications Testing Equipment & Measurement | Backshell Strain Relief | Brass Chrome | 0.165 in | 0.13 in | 3.3 mm 4.2 mm |
