DFK-MC Series

Catalog

TERMINAL BLOCK, HEADER, 3.81 MM, 2 POSITIONS, 8 A, 160 V, THROUGH HOLE VERTICAL

Part	Rear Panel Wire Connection	Rear Panel Wire Connection	Rear Panel Wire Connection	Number of Levels	Positions Per Level	Front Panel Wire Connection	Pitch	Pitch	Width [x]	Width [x]	Features	Color	Current - UL	Voltage - UL	Panel Mount Type	Panel Thickness [Max]	Panel Thickness [Min]	Panel Thickness [Min]	Panel Thickness [Max]	Width	Width
Phoenix Contact 1829345	Quick Connect Solder Eyelet	0.11 "	2.8 mm	1	2	Header Male Pins	3.81 mm	0.15 in	22.01 mm	0.867 in	Threaded Mating Lock	Green	8 A	300 V	Screw Mount - Front Flange	4 mm	0.5 mm	0.02 in	0.157 in
Phoenix Contact 1879463	Quick Connect Solder Eyelet	0.11 "	2.8 mm	1	3	Header Male Pins	3.81 mm	0.15 in			Threaded Mating Lock	Black	8 A	300 V	Screw Mount - Front Flange	4 mm	0.5 mm	0.02 in	0.157 in	1.017 "	25.82 mm
