GTC05 Series

Catalog

CONN HEADER SMD 5POS 2.54MM

Part	Number of Positions Loaded	Contact Material	Contact Shape	Fastening Type	Current Rating (Amps)	Pitch - Mating	Pitch - Mating	Connector Type	Contact Finish - Mating	Material Flammability Rating	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows	Insulation Color	Contact Type	Shrouding	Insulation Material	Style	Contact Finish - Post	Insulation Height	Insulation Height	Termination
Sullins Connector Solutions GTC05SABN-M30	All	Phosphor Bronze	Square	Push-Pull	3 A	0.1 "	2.54 mm	Header	Tin-Lead	UL94 V-0	Surface Mount	0.23 in	5.84 mm	100 çin	2.54 çm	2.54 µm	100 µin	5	600 V	-65 ░C	125 °C	1	Black	Male Pin	Unshrouded	Nylon 9T Polyamide (PA9T)	Board to Board Cable	Tin-Lead	0.1 in	2.54 mm	Solder
Sullins Connector Solutions GTC05SBSN-M89	All	Phosphor Bronze	Square	Push-Pull	3 A	0.1 "	2.54 mm	Header	Tin-Lead	UL94 V-0	Right Angle Surface Mount	0.23 in	5.84 mm	100 çin	2.54 çm	2.54 µm	100 µin	5	600 V	-65 ░C	125 °C	1	Black	Male Pin	Unshrouded	Nylon 9T Polyamide (PA9T)	Board to Board Cable	Tin-Lead	0.14 in	3.56 mm	Solder
Sullins Connector Solutions GTC05SGSN-M89	All	Phosphor Bronze	Square	Push-Pull	3 A	0.1 "	2.54 mm	Header	Tin-Lead	UL94 V-0	Right Angle Surface Mount	0.318 in	8.08 mm	100 çin	2.54 çm	2.54 µm	100 µin	5	600 V	-65 ░C	125 °C	1	Black	Male Pin	Unshrouded	Nylon 9T Polyamide (PA9T)	Board to Board Cable	Tin-Lead	0.14 in	3.56 mm	Solder
