39118 Series

Catalog

HOOK-UP STRND 18AWG RED

Part	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Jacket Color	Jacket (Insulation) Material	Ratings	Conductor Material	Voltage	Wire Gauge	Cable Type	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]	Length	Length
Belden Inc. 39118 0025000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Red	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 010100	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Black	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm	100 ft	30.5 m
Belden Inc. 39118 0055000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Green	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 0131000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Blue	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm			304.8 m	1000 ft
Belden Inc. 39118 0105000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Black	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 0085000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Gray	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 0075000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Violet	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 009100	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	White	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm	100 ft	30.5 m
Belden Inc. 39118 0045000	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Yellow	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm
Belden Inc. 39118 002100	0.3 mm	0.012 in	16	30 AWG	-40 C	105 ░C	Red	Polyphenylene Oxide (PPO)	UL Style 11028	Copper Tinned	600 V	18 AWG	Hook-Up	0.069 "	1.75 mm	100 ft	30.5 m
