86203CY Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTICONDUCTOR CABLE, XTRA GUARD FLEX, SHIELDED, 3 CONDUCTOR, 24 AWG, 0.23 MM², 1000 FT, 304.8 M
| Part | Jacket Color | Jacket (Insulation) Material | Length | Length | Number of Conductors | Shield Type | Cable Type | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Conductor Material | Conductor Strand [diameter] | Conductor Strand [custom] | Shield Material | Features | Conductor Insulation | Wire Gauge | Shield Coverage | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Slate | Poly-Vinyl Chloride (PVC) | 1000 ft | 304.8 m | 3 | Braid Foil | Multi-Conductor | 300 V | 0.04 in | 1.016 mm | Copper Tinned | 34 AWG | 10 | Aluminum Copper Tinned | Biological Compatibility Drain Wire | Poly-Vinyl Chloride (PVC) | 24 AWG | 90 % 100 % | 5.06 mm | 0.199 in | ISO 10993 UL Style 2661 |
