435-40 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN HEADER VERT 12POS 2.54MM

Part	Overall Contact Length	Pitch - Mating	Pitch - Mating	Number of Positions	Contact Length - Post	Contact Length - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Height [z]	Insulation Height [z]	Connector Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Mating	Contact Length - Mating	Mounting Type	Fastening Type	Number of Positions Loaded	Contact Type	Contact Shape	Contact Finish - Post	Number of Rows [custom]	Insulation Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Shrouding	Termination	Insulation Color	Contact Material
Mill-Max Manufacturing Corp. 435-40-212-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	12	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-238-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	38	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-208-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	8	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-214-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	14	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-272-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	72	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-204-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	4	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-232-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm		0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-220-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	20	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-240-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	40	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
Mill-Max Manufacturing Corp. 435-40-218-00-160000	0.299 in 7.6 mm	0.1 "	2.54 mm	18	0.104 in	2.64 mm	200 µin	5.08 µm	1.27 mm	0.05 in	Header	0.1 in	2.54 mm	0.125 in	3.18 mm	Through Hole	Push-Pull	All	Male Pin	Circular	Tin	2	Polycyclohexylenedimethylene Terephthalate (PCT)	5.08 µm	200 µin	Unshrouded	Solder	Black	Brass Alloy
